Automotive

Automotive Light Painting

Lighting setup

Long exposure, multiple passes brushing the body panels. A complex hero composite.

Lighting breakdown

1
Brush Source (per pass)
A focused hand-held flashlight or LED wand brushed slowly along one panel during a long exposure, controlling that panel's highlight and gradient. Repeated for each section of the car.
Hand-held flashlight / LED wand · 0.7
Fresnel
2
Optional
Background & Rim Passes
Additional passes light the background and skim the car's edges for separation, each captured as its own frame to merge in post.
Separate background + edge passes · 1
Softbox

Dark grey sports sedan at a three-quarter front angle in a black studio, headlights on, long white highlight streaks brushed along the bonnet, roof and flanks.

Base setup

One panel at a time. Composite the perfect car.

Top view

Complete setup · 1 light · 1 optional

Learning path

This setup appears in curated assignments — continue the sequence when you are ready.

Step 5/7Creative flash & camera craft
Walk with a panel or tube during a long exposure and the car becomes a canvas of trails — light painting is choreography, not a modifier recipe. Same car, same camera position; only the path of the light changes.
Light Builder Next: Projector Gobo Fashion →

Lights: 1 + 1 optional
Contrast: 7:1
Catchlight: Sweeping panel gradients
Key position: Multiple hand-held passes
Mood: Dramatic / Cinematic / Luxury
Quality: Hard Light / Specular
Subject: Automotive
Environment: Studio / Dark Background

Mood variations

Dark metallic sedan on a grey studio floor against white, long soft highlights on hood and flank with LED headlights glowing. — Showroom Clean
Many soft, overlapping passes for smooth even panels and a bright background — the classic dealership hero.

Dark sedan in a black studio with headlights on, thin white rim lines along hood and roofline and deep shadow on the lower body. — Dramatic Black
Fewer, harder passes that leave large areas in shadow; only the defining edges and a logo catch light.

Dark metallic sedan with headlights on, sharp white contour highlights and red-white light streaks behind on a black floor. — Motion Composite
Add light-trail and wheel-spin passes, then blend them with the static body frames for a dynamic, in-motion hero.

Final look

Base setup

Painting light across reflective panels one strip at a time controls every highlight and reflection that a single source never could, producing the flawless, sculpted look of high-end car ads.

Camera & framing

Exposure

ISO

ISO 100

Shutter

8 – 30s per pass

Aperture

f/11 – f/16

Lens & framing

Lens

50 – 85mm

Camera height

Low hero angle (bumper height) or eye level 3/4

Framing

Three-quarter car, full body in frame

On lens

Strong ND (6–10 stop)

With scheme: strong ND enables long shutter light painting while strobes or torches trace the car.

Read guide →

Try these settings → Key : fill ratio →

Key notes

1Lock the camera on a tripod and keep the car perfectly still — every pass must register pixel-for-pixel to composite later.
2Brush one source slowly along a single panel per exposure; the reflection you light is what defines that panel's gradient.
3Wear black and keep moving so you never record yourself; flag the source so only the panel, not the air, lights up.
4Shoot many single-area passes (body, glass, wheels, grille, background) and blend them in post — this is a composite, not one frame.
