Product

White Foam Board Product Fill

Lighting setup

Teaches passive fill on product: white foam board makes the label readable without flattening the bottle, while black cards preserve premium edge contrast.

Lighting breakdown

1
Soft Product Key
A soft LED panel camera-left creates the main reflection on bottle and packaging without overpowering the label.
LED panel through diffusion · 0.7
LED panel
2
White Foam Fill
A white foam board close to camera-right bounces just enough light into the label and product front.
White foam board · 0.36
Foam board
3
Black Card Edge
A black card on the far side creates a dark reflection band so the product still feels premium.
Black card / flag · 0.45
Flag / cutter

Product bottle — White Foam Board Product Fill lighting setup.

Base setup

Make the label readable without killing the premium shadow.

Top view

Complete setup · 1 light + 2 grip

Lights: 1
Contrast: 4:1
Catchlight: Soft panel reflection
Key position: Soft key from camera-left, foam fill camera-right
Mood: Luxury / Commercial
Quality: Soft Light / Specular / Bounced
Subject: Product
Environment: Studio / Dark Background

Mood variations

Product bottle — No Foam Fill variation of White Foam Board Product Fill. — No Foam Fill
Remove the white foam board from camera-right. The label plane falls away and the premium shadow returns — same key, but the front no longer reads.

Final look

Base setup

Small products often need a bright front plane and dark edges at the same time. White foam board lifts the label cheaply, while black cards keep the bottle and packaging from turning grey and flat. The lesson is fill versus key power — toggle No Foam Fill to see the label fail when bounce is removed, not when the key moves.

Camera & framing

Exposure

ISO

ISO 100

Shutter

1/125 - 1/200s

Aperture

f/8 - f/14

Lens & framing

Lens

90 – 100mm macro or short tele

Camera height

Slightly above table height, parallel to label plane

Framing

Hero product fill, label readable, minimal distortion

Try these settings → Key : fill ratio →

Key notes

1Place the foam board while looking at the label through camera view; a few centimeters changes readability.
2Compare hero against No Foam Fill before raising key power — if the label dies without bounce, you need fill, not more light.
3Use white foam to lift information and black card to create premium edges; do not solve everything with more key power.
4Keep the product locked on the table; reflection control is too sensitive for casual repositioning.
5Angle the board, not the bottle, when the fill patch lands too low or too high on the label.
